2027 GRAND DESIGN REFLECTION 150 250ML-SH

Specifications and Features:

• Exterior Dimensions:

  • Length: 28' 10"
  • Width: 8'
  • Height: 12' 9"

• Weights:

  • Dry Weight (UVW): 8,220 lbs
  • Gross Vehicle Weight Rating (GVWR): 9,995 lbs
  • Hitch Weight: 1,288 lbs

• Capacities:

  • Fresh Water: 55 gallons
  • Gray Water: 78 gallons
  • Black Water: 39 gallons
  • Propane Tanks: 2 (30 lbs each)

• Sleeping Capacity: 3

• Slideouts: 1

• Appliances:

  • Refrigerator: 12V, 10 cu ft
  • Cooktop Burners: 3
  • Water Heater: On Demand Tankless
  • Furnace: 30,000 BTU
  • Air Conditioner: 15,000 BTU

• Construction:

  • Aerodynamic Front Cap with Max Turn Radius
  • Gel Coated Exterior Sidewalls
  • Residential 5" Truss Rafters (16" O.C.)
  • Walk-On Roof Decking
  • Fiberglass and Radiant Foil Roof and Front Cap Insulation
  • One-Piece TPO Roof Membrane with Limited Lifetime Warranty
  • Laminated Aluminum Framed Rear Wall (R-9)
  • Laminated Aluminum Framed Side Walls (R-9)
  • Laminated Aluminum Framed Roof and End Walls in Slide Rooms (R-9)
  • Aluminum Framed Main Floor (R-30*)
  • Residential Wood Framed Roof (R-40*)

• Exterior Features:

  • 80% Tint Radius Safety Glass Windows
  • 30" Radius Entry Door
  • Outside Shower
  • Factory Installed Roof Ladder
  • Exterior Cable Hookup (Sidewall)
  • 17' One-Touch Electric Awning with LED Lights

• Interior Features:

  • Matte Black Fixtures and Hardware
  • Hardwood Galley Slide Trim Moldings
  • Solid Hardwood Drawer Fronts
  • Louvered Tread Steps to Bedroom
  • Solid Core Cabinet Stiles
  • Pre-Drilled and Screwed Cabinetry
  • Ball Bearing Full Extension Drawer Glides
  • Large Panoramic Slide Room Windows
  • Premium Congoleum Flooring
  • Ductless Flooring Throughout Living Area
  • Residential Style Window Treatment
  • Blackout Roller Shades
  • LED Lighting with Motion Sensors (Key Areas)

• Kitchen:

  • Deep Seated Stainless Steel Sink

• Electrical:

  • Marine Grade LED Hitch Light
  • Battery Disconnect Switch in Pass Thru Storage
  • 180W/370W Roof Mounted Solar Panel (floorplan specific)
  • Solar Disconnect
  • Roof Mounted Quick Connect Plugs
  • Inverter Prep
  • 60 Amp Charge Controller

• HVAC:

  • Adjustable A/C Vents
  • 35K BTU High Capacity Furnace

• Plumbing:

  • Brass Fittings
  • Extra Large 2" Fresh Water Drain Valve
  • On Demand Water Heater
  • Easy Access Low Point Drain Valves
  • High-Capacity Water Pump with Interior and Exterior Switch

• Bedroom:

  • Functional Wardrobe Closet
  • Oversized Bed Base Storage
  • 60 x 80 Mattress with Residential Bedspread
  • Bedroom Heat Registers
  • Washer/Dryer Prep (On Most Models)

• Bathroom:

  • 30 x 36 Residential Walk-In Shower
  • Heat Duct and A/C Vents in Bathroom
  • Power Vent Fan
  • Large Vanity Top w/ Deep Sink
  • Large Medicine Cabinet with Mirror

• Appliance:

  • 12V 10 or 16 Cu. Ft. Refrigerator (floorplan specific)

• Electronics:

  • High Definition LED TV
  • AM/FM/HDMI/Bluetooth Stereo
  • Compass Connect
  • Tire Linc TPMS

• Running Gear:

  • Anti-Lock Braking (ABS) w/ Sway Control
  • CURT Touring Coil Suspension System
  • Aluminum Wheels with E-Rated Tires
  • Under Carriage Spare Tire and Carrier

• Packages:

  • Peace of Mind Package
  • Ultimate Power Package
  • Solar Protection Package
